Residential Openers

Home » Residential Garage Doors » Residential Openers
Residential Openers 2019-12-18T08:55:14+00:00

Residential Openers

Autolift is able to supply install and maintain a range of residential openers for all applications and can recommend the opener most suitable to your application via the Merlin product range.

The Merlin range is brought to you by the largest manufacturer of Residential garage door openers in the world, suiting all types of doors from roller, sectional, and tilt.


SILENTDRIVE ESSENTIAL MR655MYQ

The NEW SilentDrive Essential is myQ compatible, with bright LED lighting, quiet operation and includes 2 x premium hand held remotes;

  • 24 DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 16.5m2
  • Drum rotations: 4.5
  • Max Door weight: up to 100kg
  • Max peak pulling force: 500N
  • Minimum side room 45mm
  • 433.30, 434.54, 433.92 MHz AM radio with Security+2.0 encrypted rolling code technology
  • Up to 64 memory registers
  • Courtesy light: LED
  • Noise rating: 1M 57DB

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MR655MYQ SilentDrive Essential

SILENTDRIVE ELITE MR855MYQ

The latest Merlin opener to power your garage door! At last, you can monitor and control your garage door opener away from home through the Merlin myQ app via your smartphone, tablet or computer;

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 18m2
  • Drum rotations: 4.5
  • Max door weight: up to 120kg
  • Max peak pulling force: 550N
  • Minimum side room 45mm
  • 433.30, 434.54, 433.92 MHz AM radio with Security+2.0 encrypted rolling code technology
  • Up to 64 memory registers
  • Courtesy light: LED
  • Noise rating 1M: 59DB
  • myQ Technology

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MR865MYQ SilentDrive Elite

WEATHERDRIVE™ MR550EVO

With a market leading weather resistant IP34 design, slimline design to fit into the tightest of spaces and LED lighting as standard, makes WeatherDrive the perfect option for powering sheds and carport roller doors.

Compliant to Australian & New Zealand Standards, WeatherDrive comes with a 3 Year Warranty for complete peace of mind and Merlin Security+2.0 encryption rolling code technology for operation under all environment conditions and greater distance than ever before;

  • IP34 housing
  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Minimum side room 40mm
  • Rated door area up to 15m²
  • Max door weight: up to 100kg
  • Drum rotations: 5.5
  • Max peak pulling force: 500 N
  • 433.30, 434.54, 433.92 MHz AM radio with Security+2.0 encrypted rolling code technology
  • Up to 64 memory registers
  • Courtesy light: LED
  • Noise rating 1M: 51DB
  • Soft start/stop function
MR550EVO WeatherDrive

COMMANDER ULTIMATE MJ3800MYQ

Open Up Possibilities, Commander Ultimate is the most premium opener within the Merlin sectional range with built-in myQ Wi-Fi & integrated Battery Backup with Security+2.0. Jam packed with many accessories including a myQ remote LED light, Smart Control Panel, Automatic Door Lock, Cable Tension Monitor, 2 x Premium+ remotes;

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 16.5m²
  • Max door weight: up to 130kg without The Protector System (Safety IR Beams) and 230kg with The Protector System (Safety IR Beams)
  • Max peak pulling force: 600 N
  • 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
  • Up to 40 remote controls, 4 wireless key entry systems and 16 myQ devices
  • Min headroom required: 216mm

Watch the Commander Ultimate video here.

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MJ3800MYQ Ultimate

COMMANDER EXTREME MS125MYQ

Designed for extreme weather conditions & heavy custom doors, Commander Extreme is myQ compatible, with heavy lifting power of 150kg or 286kg (with beams) plus new powerful LED lighting and Battery Backup.

Powerful, quiet and compliant to Australian & New Zealand standards (AS/NZS 60335-2-95), enjoy complete peace of mind with the market leading 7 Year Warranty and built in premium safety reversal technology, to ensure your family and possessions are protected. Loaded with Merlin Security+2.0 encryption rolling code technology means perfect operation under all environment conditions and from a greater distance than ever before;

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 20m²
  • Max door weight: up to 150kg / 286kg (with beams installed)
  • Max peak pulling force: 1200 N
  • C-rail with chain drive
  • 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
  • Up to 64 memory registers
  • Courtesy light: Powerful LED Lighting
  • Min headroom required: 30mm

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MS125MYQX Commander Extreme

COMMANDER ELITE MS105MYQ

Australia’s favourite opener, Commander Elite is myQ compatible & Battery Backup compatible, with heavy lifting power of 150kg and new powerful LED lighting. Powerful, quiet and compliant to Australian & New Zealand Standards, enjoy complete peace of mind with the market leading 7 Year Warranty and built in premium safety reversal technology, to ensure your family and possessions are protected. Loaded with Merlin Security+2.0 encryption rolling code technology means perfect operation under all environment conditions and from a greater distance than ever before;

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 20m²
  • Max door weight: up to 150kg
  • Max peak pulling force: 1000 N
  • C-rail with belt drive
  • 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
  • Up to 64 memory registers
  • Courtesy light: Powerful LED Lighting
  • Min headroom required: 30mm

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MS105MYQ Commander Elite

COMMANDER ESSENTIAL MS65MYQ

Merlin’s Commander Essential is small in size, big on features.
This sectional garage door opener has the latest security and multi frequency technology, and includes a 5 Year Warranty;

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 13.5m²
  • Max door weight: up to 90kg
  • Max peak pulling force: 600 N
  • C-rail with belt drive
  • 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
  • Up to 64 memory registers
  • Courtesy light: LED
  •  Min headroom required: 30mm

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

MS65MYQ Commander Essential

MYQ REMOTE LED LIGHT

3 Convenient Ways to Control Your myQ Remote LED Light;

  • Operate via any compatible Merlin Security +2.0 garage door remote control (1 supplied). No garage door opener required.**
  • Control and monitor from anywhere in the world via the myQ smartphone app. You can also schedule to turn the light on or off 24/7.*
  • Sync with your Merlin garage door opener to turn the light on when the door is activated.**

Easy Mounting;

  • Easily attaches to either ceiling or wall.
  • Supplied with 1.8m power lead.
  • Multiple myQ Remote LED Lights can be added to your garage or workspace.

Ultra Bright LED;

  • 1,500 lumens to brighten up any garage or workspace.
  • Wide, diffuse light output to illuminate into the corners of your garage or workspace.

Compatible Merlin Remote Controls;

  • Premium+ Four Button Remote Control (E960M)
  • Three Button Remote Control with Car Visor Clip (E943M)
  • Single Button Remote Control with Car Visor Clip (E940M)
  • Four Button Slider Remote Control (E950M)
  • Three Button Mini Remote Control (E945M)

Compatible Merlin myQ Garage Door Openers;

  • Commander Essential (MS65MYQ)
  • Commander Elite (MS105MYQ)
  • Commander Extreme (MS125MYQ)
  • SilentDrive™ Essential (MR655MYQ)
  • SilentDrive™ Elite (MR855MYQ)
  • Commander Ultimate (MJ3800MYQ)

* Requires a myQ Gateway device and an active myQ account.
** Only available on compatible models.

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

827AU MYQ Remote LED Light

MYQ CONNECTIVITY BUNDLE

Add monitoring and control away from home via the Merlin myQ app for smart devices including Apple Watch. Includes myQ Gateway and the Protector System™ (Safety IR Beams) to protect your loved ones and belongings;

  • Monitor and control away from home
  • Receive alerts and notifications
  • myQ Scheduling*
  • myQ Touch ID**

Compatible with garage door openers bearing the myQ Compatible logo;

  • Commander Essential (MS65MYQ)
  • Commander Elite (MS105MYQ)
  • Commander Extreme (MS125MYQ)
  • SilentDrive™ Essential (MR655MYQ)
  • SilentDrive™ Elite (MR855MYQ)

*Linking your myQ account to partners may require a subscription fee.
** Available only for iPhone and iPad products that offer fingerprint functionality.

myQ is only compatible with iOS devices with firmware 11, 12 and 13, and Android devices with firmware 7, 8 and 9. Before purchasing or installing myQ on your device, please ensure you have access to a device with the appropriate firmware.

M828AU774 MYQ Connectivity
